Hi,
I tried some workflow that perfectly works for S1 and ALOS-1 data and theoreticaly should work for SAOCOM dual pol as well:
SAOCOM slc → calibration → gen. POL matrix C2 → POL decomp (Model-Based Dual Pol decomp)
But instead of nice results I have got:
“A problem occurred during the target product initialisation.
Type: OperatorException
Message: Dual-pol product with VH-VV or HH-HV polarisation is expected”
Details:
org.esa.snap.core.gpf.OperatorException: Dual-pol product with VH-VV or HH-HV polarization is expected
at org.csa.rstb.polarimetric.gpf.PolarimetricDecompositionOp.getPolarization(PolarimetricDecompositionOp.java:323)
at org.csa.rstb.polarimetric.gpf.PolarimetricDecompositionOp.createDecomposition(PolarimetricDecompositionOp.java:299)
at org.csa.rstb.polarimetric.gpf.PolarimetricDecompositionOp.initialize(PolarimetricDecompositionOp.java:195)
Caused: org.esa.snap.core.gpf.OperatorException: Dual-pol product with VH-VV or HH-HV polarization is expected
at org.esa.snap.engine_utilities.gpf.OperatorUtils.catchOperatorException(OperatorUtils.java:434)
at org.csa.rstb.polarimetric.gpf.PolarimetricDecompositionOp.initialize(PolarimetricDecompositionOp.java:203)
at org.esa.snap.core.gpf.internal.OperatorContext.initializeOperator(OperatorContext.java:528)
at org.esa.snap.core.gpf.internal.OperatorContext.getTargetProduct(OperatorContext.java:298)
at org.esa.snap.core.gpf.Operator.getTargetProduct(Operator.java:359)
at org.esa.snap.core.gpf.GPF.createProductNS(GPF.java:333)
at org.esa.snap.core.gpf.GPF.createProduct(GPF.java:308)
at org.esa.snap.core.gpf.GPF.createProduct(GPF.java:287)
at org.esa.snap.graphbuilder.rcp.dialogs.SingleOperatorDialog.createTargetProduct(SingleOperatorDialog.java:175)
[catch] at org.esa.snap.graphbuilder.rcp.dialogs.SingleOperatorDialog.onApply(SingleOperatorDialog.java:287)
at org.esa.snap.ui.AbstractDialog.lambda$initUI$6(AbstractDialog.java:521)
at java.desktop/javax.swing.AbstractButton.fireActionPerformed(AbstractButton.java:1972)
at java.desktop/javax.swing.AbstractButton$Handler.actionPerformed(AbstractButton.java:2314)
at java.desktop/javax.swing.DefaultButtonModel.fireActionPerformed(DefaultButtonModel.java:407)
at java.desktop/javax.swing.DefaultButtonModel.setPressed(DefaultButtonModel.java:262)
at java.desktop/javax.swing.plaf.basic.BasicButtonListener.mouseReleased(BasicButtonListener.java:279)
at java.desktop/java.awt.AWTEventMulticaster.mouseReleased(AWTEventMulticaster.java:297)
at java.desktop/java.awt.Component.processMouseEvent(Component.java:6621)
at java.desktop/javax.swing.JComponent.processMouseEvent(JComponent.java:3398)
at java.desktop/java.awt.Component.processEvent(Component.java:6386)
at java.desktop/java.awt.Container.processEvent(Container.java:2266)
at java.desktop/java.awt.Component.dispatchEventImpl(Component.java:4996)
at java.desktop/java.awt.Container.dispatchEventImpl(Container.java:2324)
at java.desktop/java.awt.Component.dispatchEvent(Component.java:4828)
at java.desktop/java.awt.LightweightDispatcher.retargetMouseEvent(Container.java:4948)
at java.desktop/java.awt.LightweightDispatcher.processMouseEvent(Container.java:4575)
at java.desktop/java.awt.LightweightDispatcher.dispatchEvent(Container.java:4516)
at java.desktop/java.awt.Container.dispatchEventImpl(Container.java:2310)
at java.desktop/java.awt.Window.dispatchEventImpl(Window.java:2780)
at java.desktop/java.awt.Component.dispatchEvent(Component.java:4828)
at java.desktop/java.awt.EventQueue.dispatchEventImpl(EventQueue.java:775)
at java.desktop/java.awt.EventQueue$4.run(EventQueue.java:720)
at java.desktop/java.awt.EventQueue$4.run(EventQueue.java:714)
at java.base/java.security.AccessController.doPrivileged(AccessController.java:400)
at java.base/java.security.ProtectionDomain$JavaSecurityAccessImpl.doIntersectionPrivilege(ProtectionDomain.java:87)
at java.base/java.security.ProtectionDomain$JavaSecurityAccessImpl.doIntersectionPrivilege(ProtectionDomain.java:98)
at java.desktop/java.awt.EventQueue$5.run(EventQueue.java:747)
at java.desktop/java.awt.EventQueue$5.run(EventQueue.java:745)
at java.base/java.security.AccessController.doPrivileged(AccessController.java:400)
at java.base/java.security.ProtectionDomain$JavaSecurityAccessImpl.doIntersectionPrivilege(ProtectionDomain.java:87)
at java.desktop/java.awt.EventQueue.dispatchEvent(EventQueue.java:744)
at org.netbeans.core.TimableEventQueue.dispatchEvent(TimableEventQueue.java:136)
at java.desktop/java.awt.EventDispatchThread.pumpOneEventForFilters(EventDispatchThread.java:203)
at java.desktop/java.awt.EventDispatchThread.pumpEventsForFilter(EventDispatchThread.java:124)
at java.desktop/java.awt.EventDispatchThread.pumpEventsForHierarchy(EventDispatchThread.java:113)
at java.desktop/java.awt.EventDispatchThread.pumpEvents(EventDispatchThread.java:109)
at java.desktop/java.awt.EventDispatchThread.pumpEvents(EventDispatchThread.java:101)
at java.desktop/java.awt.EventDispatchThread.run(EventDispatchThread.java:90)
